Ubiquiti - Lettore OSDP per interni/esterni con supporto per schede NFC e Touch Pass, compatibile con UniFi Retrofit Hub utilizzando il cablaggio esistente.
Codice: ART-246429 EAN: 810177161677 MPN: UA-Retrofit-Hub-2-USATO
Prodotto nuovo, usato per dimostrazione, confezione originale.
CONTENUTO DELLA CONFEZIONE
Scheda Tecnica
Scheda Tecnica
Overview
Dimensions
140 x 120 x 45 mm
(5.5 x 4.7 x 1.8")
Supported Doors
2
Maximum User Count
10,000
Input Terminals
(2) Third-party Wiegand Reader / UniFi Retrofit Reader
(2) Door exit request
(2) Door position
(1) Emergency
Power Method
12/24V DC
NDAA Compliant
Yes
UL 294 Level
Destructive attack: Level I
Line security: Level I
Endurance: Level I
Standby power: Level I
Mechanical
Weight
420 g (14.8 oz)
Enclosure Material
Polycarbonate
Mount Material
SGCC steel
Mounting
Din-rail (Included)
Hardware
Digital Input
(2) Third-party Wiegand Reader / UniFi Retrofit Reader
(2) Door exit request
(2) Door position
(1) Emergency
Dry Output Relay
Lock: rated 30V DC, up to 1A
Aux: rated 30V DC, up to 1A
Powered Output Relay
12V Lock: 12V DC, up to 1A
24V Lock: 24V DC, up to 0.5A
Indoor and Outdoor Use
Indoor only
Ambient Operating Temperature
-10 to 40° C
(14 to 104° F)
Ambient Operating Humidity
5 to 90% noncondensing
Networking Interface
(2) 10/100 MbE RJ45 ports
Power Supply
DC 12/24V
Max. Power Consumption
50W
Reader Power Output
12V DC, up to 0.5A
LEDs
W/B Learn More
Buttons
(1) Factory reset
(2) 12V/Dry/24V switch
Recommend Max. Cable Length
UA-Retrofit-Reader (250mA)
18 UACC-Cable-DoorLockRelay length: 152.4 m (500 ft)
UA-Lock-Electric
(400mA)
24 AWG length: 25 m (82 ft)
22 AWG length: 42 m (138 ft)
20 AWG length: 66 m (217 ft)
18 UACC-Cable-DoorLockRelay length: 100 m (328 ft)
UA-Lock-Magnetic-540kg (500mA)
24 AWG length: 20 m (66 ft)
22 AWG length: 32 m (105 ft)
20 AWG length: 51 m (167 ft)
18 UACC-Cable-DoorLockRelay length: 80 m (262 ft)
UA-Lock-Magnetic-270kg (800mA)
24 AWG length: 12 m (39 ft)
22 AWG length: 20 m (66 ft)
20 AWG length: 30 m (98 ft)
18 UACC-Cable-DoorLockRelay length: 46 m (151 ft)
Other locks
(1A)
24 AWG length: 9 m (30 ft)
22 AWG length: 15 m (49 ft)
20 AWG length: 24 m (79 ft)
18 UACC-Cable-DoorLockRelay length: 36 m (118 ft)
PoE Cabling Requirements
Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site.
The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm² ) for patch cords; 24 AWG (0.21 mm² ) for horizontal or riser cable.
UL 294 Statement
Compliance with IEEE 802.3 specifications was not verified as part of UL 294.
The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits.
CAN/ULC-60839-11-1 Grade
Grade assignment: I
Certifications
CE, FCC, IC, UL 294, CAN/ULC-60839-11-1
Document number, and issue date and/or revision level
UA-Retrofit-Hub-2, V01
Software
Management Application
Access
Software Information
The software version can be checked at https://unifi.ui.com
