Ubiquiti - UPS-2U-Pro - UniFi-managed 2.2kVA rackmount UPS with pure sine wave output, 9 individually controllable outlets with per-port power monitoring and remote power cycling, a hot-swappable 720Wh battery, and up to 22 minutes of runtime at half load 990W. Supports Graceful Shutdown for UNVR and UNAS, and NUT compatibility for third-party devices.

Codice: ART-244700 EAN: 810177161875 MPN: UPS-2U-Pro

Scheda Tecnica Scheda Tecnica

Dimensions

442.4 x 87.4 x 630 mm
(17.4 x 3.4 x 24.8")

Weight

32 kg (70.5 lb)

Enclosure Material

Galvanized steel

Form Factor

Rack mount (2U)

Weatherproofing

IP20

Management

Ethernet

Networking Interface

(1) 100/10 MbE port for network connection
(2) GbE ports for surge in/out

Power

(1) OVC II AC in: C20 socket
(8) Battery backup/surge protection: C13
(1) Battery backup/surge protection: C19


Capacity

2200VA/1980W

Type

Line interactive

Input Voltage Range

170–280V AC

Power Method

(1) TN system, 230V AC, 10.2A Max., 50/60 Hz

Nominal Input Voltage

230V AC

Output Voltage

230V AC

Nominal Output Voltage

230V AC

Frequency Range

AC mode: 50/60 Hz ±5 Hz (Auto sensing)
Battery mode: 50 Hz ±1 Hz

AC Voltage Regulation

±1.5% (Battery mode)

Transfer Time

6 ms typical; 10 ms max. (Battery mode)

Wave Form

Pure sine wave (Battery mode)

Battery Type

(1) Lead Acid 72V, 10Ah

Runtime

Full load: 9 min
Half load: 22 min

Battery Charging Time

8 hours recovery to 90% capacity

Overload at On-Line Mode

103–120%  5 min go to fault
120–150% 10 sec go to fault
150% 1 sec go to fault

Overload at Battery Mode

103–120%  1 min go to fault
120–150% 10 sec go to fault
150% 0.5 sec go to fault

Short Circuit Protection at On-Line Mode

Breaker, 250V AC, 16A

Emergency Power Off (EPO)

✓

Display

3.7” touchscreen

Buttons

(1) Power
(1) Factory reset
(1) Circuit breaker

LEDs

Status

Off: device not turned on
Flashing white: initializing / factory default
Steady white: waiting for adoption
Steady blue: device adoption and working
Flashing blue: battery mode
Alternating white/blue: firmware upgrading
Rapid flashing blue: locate
Steady red: warning
Flashing red: low battery

Ethernet

✓

Operating Altitude

3,000 m (1.9 mi)

Operating Environment

Pollution Degree 2

Ambient Storage Temperature

-15 to 50° C (5 to 122° F)

Ambient Operating Temperature

0 to 40° C (32 to 104° F)

Ambient Operating Humidity

0 to 95% noncondensing

Certifications

CE, IEC 62040-1

Application Requirements

Mobile Apps

iOS™: Version 10.36.1 and later
Android™: Version 10.39.3 and later

UniFi Network

Version 10.5.67 and later

IN THE BOX
